CONTINUOS ZOOM LENS
TCM-640/TCC-640 provided with various continuous optical zoom.
DIGITAL IMAGE STABLIZER
It works to compensate the vibration of the camera from unstable move
SPECIFICATIONS
Detector Type
Cooled InSb FPA
Pixel Size
640(H) X 512(V)
Pixel Pitch
15㎛
Spectral Response
3㎛ ~ 5㎛
Frame Rate
30 ~ 200Hz
Cold Shield
F/5.5
NETD
<20mK typical (without lens)
Cooler Type
Rotary Stirling Cooler, MTBF: 10,000Hours
Cool-down Time
<7 Minutes (@25˚C, Max)
Output Frequency
NTSC: 59.94Hz (30fps), PAL: 50Hz (25fps)
Video Output
CVBS: 1.0Vp-p / 75Ω, Option (Camera Link, HD-SDI, BT.1120)
Resolution
640(H) x 512(V)
Interface Protocol
RS-232, RS-422
Baud Rate
2400/4800/9600/19200/38400/57600/115200 bps
Interface Type
DSUB-15P
Lens
20 to 275mm (28° ~ 1.9°)/ 48.5 to 700mm (11.9° ~ 0.8°)/ 28 to 850mm (19.8° ~ 0.3°), Continuos
Dimensions (WxHxD)
Without Lens: 77.6 x 67.8 x 120.3mm, 20 to 275mm: 100.7 x 83.9 x 188.2mm, 48.5 to 700mm: TBD, 28 to 850mm: TBD
Weight
Without Lens: 615.4g, 20 to 275mm: 1.15kg, 48.5 to 700mm: TBD, 28 to 850mm: TBD
Power Consumption
DC20 ~ DC32V/850mA [20.4W] (Max)
Power Supply
DC24V, 1A
Operating Temperature
-32˚C ~ 55˚C
Storage Temperature
-40˚C ~ 65˚C
